Awlcraft 3000 Topcoat — Gallon (Acrylic Urethane Marine Finish)

Awlcraft 3000 is a premium, two-component acrylic urethane marine topcoat engineered for professional spray application on yachts, sportfish, and performance craft. Designed to deliver exceptional flow, leveling, and a deep buffable high-gloss finish, Awlcraft 3000 provides outstanding color clarity and long-term gloss retention in demanding marine environments.

This system is ideal for above-the-waterline applications including hull sides, superstructures, and deck components. Not recommended for constant immersion.

Why Choose Awlcraft 3000?

• High-gloss, buffable finish for extended service life
• Enhanced color depth and vibrancy using modern pigment technology
• Fast drying with superior flow and leveling characteristics
• Repairable and blendable compared to traditional linear polyurethane systems
• Compatible with Awlgrip epoxy primers and fairing systems

Mixing & Spray Application

• Mix Ratio: 2:1 by volume (Awlcraft 3000 Base : Awlcat #2 G3010 Converter)
• Reduction: 15–33% with Awlgrip spray reducers (T0001, T0002, T0003, or T0005) to reach 11–15 seconds DIN 4 or 16–18 seconds Zahn #2
• Application: Typically 2–3 coats by air-atomized spray
• Flash Time: 15–45 minutes after first coat; 30–45 minutes between subsequent coats
• Spray Setup: 1.0–1.2 mm fluid tip; 2–2.5 bar (29–36 psi)

For reducer selection, temperature requirements, and detailed spray setup guidance, visit our dedicated Awlcraft 3000 Technical Support Guide.

Coverage & Drying Performance

• Theoretical Coverage: ~741 ft² per gallon per coat @ ~1.4 mil DFT (based on 100% transfer efficiency; actual coverage will vary)
• Recommended Dry Film Thickness: ~1.4 mils per coat
• Tape-Free: Approximately 24 hours at 77°F (25°C)
• Light Service: Approximately 3 days at 77°F
• Full Cure: Approximately 21 days
• Pot Life: Approximately 7 hours under standard conditions

Surface Preparation Requirements

For best results, apply over properly prepared Awlgrip epoxy primers such as Awlgrip 545 or Awlquik. Sand primer surfaces smooth (P320–P400) and ensure the substrate is clean, dry, and free of contaminants before topcoat application.

If more than 24 hours elapse before recoating, sand or scuff the surface prior to applying additional coats.

Package Contents

• 1 US Gallon Awlcraft 3000 Topcoat Base (color)
• Requires Awlcat #2 G3010 Converter (sold separately)
• Requires appropriate Awlgrip spray reducer (sold separately)

Need Technical Help?

Mix ratios, reducer selection, film thickness calculations, cure schedules, and repair procedures are covered in detail in our Awlcraft 3000 Technical Support Section.

Fiberglass Florida is your source for professional Awlgrip and Awlcraft guidance. If you have application or compatibility questions, contact our marine coatings support team.
